LWR300

Laser Wind Radar

? Wind speed and wind direction measurement at the height     30m～800m
? 1550nm laser multipoint scanning technology
? Built-in integrated digital compass with auto north-seeking
? Support RS232/485,USB,LAN,Wi-Fi
? Built-in GPS+GPRS module to realize the remote     communication and positioning
? Built-in battery could support continuous work for more than     1 hour

Wind Measurement
Working wavelength	1550nm
Height range	30m ~ 800m(Max. 1000m)
Wind speed range	0.5m/s ~ 60m/s
Wind direction range	0 ~ 360°
Wind speed accuracy	0.1m/s
Wind direction accuracy	2°
Height resolution	Minimum measurement layer at 10m (within detection range or manual setting is supported)
Time resolution	10s

Temperature Measurement
Temperature range	-30℃~50℃
Temperature accuracy	±0.3℃，±0.2℃(5℃~35℃)
Temperature resolution	0.1℃

Humidity Measurement
Humidity range	0%RH~100%RH
Humidity accuracy	±3%RH (10%RH~90%RH)，±5%RH(90%RH~100%RH)
Humidity resolution	0.1%RH

Pressure Measurement
Pressure range	800hPa~1100hPa
Pressure accuracy	±0.3hPa(0~50℃)，±0.5hPa(-30~0℃)
Pressure resolution	0.1hpa

General
Working time	≥8h with external power supply, ≥1h with battery
Power consumption	50~60W
Power supply	24V DC
Communication interface	RS232/485、USB、LAN、Wi-Fi
Positioning	GPS, BeiDou, GLONASS, Galileo
Compass	Triaxial digital compass, auto north-seeking
Working environment	-30 ~ 50℃
Storage temperature	-50℃～85℃
Humidity range	0%RH~ 100%RH
Protective performance	rain-proof, salt mist resistance, anti-sand dust, anti-vibration, impact resistance
Housing	aviation aluminum alloy
Weight	about 60KG
Dimensions	550×540×640mm
